AIRBOSS® SG-65H Industrial Pneumatic Tool
SKU SG-65H
Type Air Straight Grinder
Email for Quote
Request a Quote
At a glance
Key Specifications
Performance and fit information for this exact model.
Wheel Capacity
2 1/2×1/2×3/8 in
Collet Size
5/16" / 1/4"
Free Speed
14600 rpm
Power
0.64 hp
Spindle Thread
W3/8-16
18-month limited warranty. See full warranty terms.
Product Details
Product Highlights
AIRBOSS SG-65H is part of the industrial pneumatic tool catalog. Product photos are shown for model identification. Request a quote to confirm specifications, configuration, lead time, and pricing.
View all specifications 13 details
Performance
- Free Speed
- 14600 rpm
- Power
- 0.64 hp
Tool & Capacity
- Wheel Capacity
- 2 1/2×1/2×3/8 in
- Collet Size
- 5/16" / 1/4"
- Spindle Thread
- W3/8-16
- Model
- SG-65H
- Product Type
- Air Straight Grinder
Air Requirements
- Air Consumption
- 19.4 CFM
- Air Inlet
- 3/8"
- Air Pressure
- 6.3 kg/cm²
- Recommended Hose
- 3/8"
Dimensions
- Overall Length
- 14.44 in
- Weight
- 3.3 lb
Parts & Service
Parts for SG-65H
Open the model-specific exploded view to identify the part number, then contact us for availability.
